Features of Dongfeng Cummins generator set

First, the structural advantages of diesel engine

1. Advanced design and excellent manufacturing, adapt to severe working conditions, and have strong ability of high intensity and heavy load operation.

2. Holset wastegate has better power performance.

3. The integrated design of cylinder block, cylinder head and other parts "one piece of multi-function" reduces the number of connecting parts. The parts are 40% less than other similar engines, and the failure rate is greatly reduced.

4. Excellent reliability adopts forged steel camshaft and crankshaft, high strength cylinder block design, many parts are cast on the cylinder block, with high rigidity, high pressure resistance and long service life.

5. Rotor high pressure fuel pump, less energy loss, stronger power, lower fuel consumption, and effectively reduce noise. Second, service advantages

Record the customer's fault, deal with the corresponding problems, and inform the customer of the exact time to visit. To make three kinds of commitments: to establish a 6-hour service commitment in the Pearl River Delta; to make a 12-hour service commitment in Guangdong Province; to make a 24-hour service commitment in six provinces of South China; to make a professional plan and inform customers in a timely manner after the Department studies the remote mountainous areas and special locations.

Dongfeng Cummins series power units

/24KW-450KW

24KW 30KW 40KW 50KW 60KW 80KW 100KW 120KW 150KW 180KW 200KW 280KW 300KW 350KW 400KW 450KW

Power parameter list of Dongfeng Cummins diesel generator set

Open type

Unit model:VGF-DKKJ-24
Main power:21KWReserve power:24KW
Current:37ADiesel engine model:4B3.9-G1
Number of cylinders:4(PCS)Bore x stroke:102*120mm
Fuel consumption power:212g/kw.hUnit size:1650/1388/830mm L/W/H
Unit weight:980kg
Unit model:VGF-DKKJ-30
Main power:36KWReserve power:40KW
Current:64ADiesel engine model:4BT3.9-G1
Number of cylinders:4(PCS)Bore x stroke:102*120mm
Fuel consumption power:212g/kw.hUnit size:1650/1388/830mm L/W/H
Unit weight:1020kg
Unit model:VGF-DKKJ-40
Main power:36KWReserve power:40KW
Current:64ADiesel engine model:4BT3.9-G2
Number of cylinders:4(PCS)Bore x stroke:102*120mm
Fuel consumption power:212g/kw.hUnit size:1800/1388/830mm L/W/H
Unit weight:1060kg
Unit model:VGF-DKKJ-50
Main power:50KWReserve power:55KW
Current:90ADiesel engine model:4BTA3.9-G2
Number of cylinders:4(PCS)Bore x stroke:102*120mm
Fuel consumption power:220g/kw.hUnit size:1800/1388/830mm L/W/H
Unit weight:1090kg
Unit model:VGF-DKKJ-60
Main power:70KWReserve power:80KW
Current:126ADiesel engine model:4BTA3.9-G11
Number of cylinders:4(PCS)Bore x stroke:102*120mm
Fuel consumption power:210g/kw.hUnit size:1950/1388/830mm L/W/H
Unit weight:1130kg
Unit model:VGF-DKKJ-80
Main power:80KWReserve power:92KW
Current:144ADiesel engine model:6BT5.9-G1
Number of cylinders:6(PCS)Bore x stroke:102*120mm
Fuel consumption power:221g/kw.hUnit size:2200/1440/850mm L/W/H
Unit weight:1450kg
Unit model:VGF-DKKJ-100
Main power:106KWReserve power:116KW
Current:190ADiesel engine model:6BTA5.9-G2
Number of cylinders:6(PCS)Bore x stroke:102*120mm
Fuel consumption power:212g/kw.hUnit size:2280/1450/850mm L/W/H
Unit weight:1650kg
Unit model:VGF-DKKJ-120
Main power:120KWReserve power:155KW
Current:216ADiesel engine model:6BTAA5.9-G2
Number of cylinders:6(PCS)Bore x stroke:102*120mm
Fuel consumption power:215g/kw.hUnit size:2280/1450/850mm L/W/H
Unit weight:1690kg
Unit model:VGF-DKKJ-150
Main power:163KWReserve power:180KW
Current:293ADiesel engine model:6CTA8.3-G1
Number of cylinders:6(PCS)Bore x stroke:114*135mm
Fuel consumption power:212g/kw.hUnit size:2390/1560/950mm L/W/H
Unit weight:2080kg
Unit model:VGF-DKKJ-180
Main power:183KWReserve power:203KW
Current:329ADiesel engine model:6CTAA8.3-G2
Number of cylinders:6(PCS)Bore x stroke:114*135mm
Fuel consumption power:209g/kw.hUnit size:2480/1600/1020mm L/W/H
Unit weight:2200kg
Unit model:VGF-DKKJ-200
Main power:200KWReserve power:242KW
Current:360ADiesel engine model:6LTAA8.9-G2
Number of cylinders:6(PCS)Bore x stroke:114*145mm
Fuel consumption power:199g/kw.hUnit size:2480/1600/1020mm L/W/H
Unit weight:2290kg
Unit model:VGF-DKKJ-280
Main power:280KWReserve power:308KW
Current:504ADiesel engine model:QSM11-G2
Number of cylinders:6(PCS)Bore x stroke:125*147mm
Fuel consumption power:193g/kw.hUnit size:2900/1680/1100mm L/W/H
Unit weight:3150kg
Unit model:VGF-DKKJ-300
Main power:340KWReserve power:380KW
Current:612ADiesel engine model:6ZTAA13-G3
Number of cylinders:6(PCS)Bore x stroke:130*163mm
Fuel consumption power:197g/kw.hUnit size:2900/1680/1100mm L/W/H
Unit weight:3220kg
Unit model:VGF-DKKJ-350
Main power:390KWReserve power:415KW
Current:702ADiesel engine model:6ZTAA13-G2
Number of cylinders:6(PCS)Bore x stroke:130*163mm
Fuel consumption power:197g/kw.hUnit size:3150/1880/1250mm L/W/H
Unit weight:3680kg
Unit model:VGF-DKKJ-400
Main power:400KWReserve power:415KW
Current:720ADiesel engine model:6ZTAA13-G4
Number of cylinders:6(PCS)Bore x stroke:130*163mm
Fuel consumption power:197g/kw.hUnit size:3260/2030/1350mm L/W/H
Unit weight:3890kg
Unit model:VGF-CKKJ-450
Main power:450KWReserve power:470KW
Current:810ADiesel engine model:QSZ13-G3
Number of cylinders:6(PCS)Bore x stroke:130*163mm
Fuel consumption power:193g/kw.hUnit size:3450/2100/1450mm L/W/H
Unit weight:4350kg
24KW 30KW 40KW 50KW 60KW 80KW 100KW 120KW 150KW 180KW 200KW 280KW 300KW 350KW 400KW 450KW

潍柴系列柴油发电机组各功率段参数列表

静音机型

Unit model:VGF-DKJY-24
Main power:21KWReserve power:24KW
Current:37ADiesel engine model:4B3.9-G1
Number of cylinders:4(PCS)Bore x stroke:102*120mm
Fuel consumption power:212g/kw.hUnit size:2300/1450/1000mm L/W/H
Unit weight:1320kg
Unit model:VGF-DKJY-30
Main power:36KWReserve power:40KW
Current:64ADiesel engine model:4BT3.9-G1
Number of cylinders:4(PCS)Bore x stroke:102*120mm
Fuel consumption power:212g/kw.hUnit size:2300/1450/1000mm L/W/H
Unit weight:1360kg
Unit model:VGF-DKJY-40
Main power:36KWReserve power:40KW
Current:64ADiesel engine model:4BT3.9-G2
Number of cylinders:4(PCS)Bore x stroke:102*120mm
Fuel consumption power:212g/kw.hUnit size:2500/1450/1000mm L/W/H
Unit weight:1450kg
Unit model:VGF-DKJY-50
Main power:50KWReserve power:55KW
Current:90ADiesel engine model:4BTA3.9-G2
Number of cylinders:4(PCS)Bore x stroke:102*120mm
Fuel consumption power:220g/kw.hUnit size:2500/1450/1000mm L/W/H
Unit weight:1480kg
Unit model:VGF-DKJY-60
Main power:70KWReserve power:80KW
Current:126ADiesel engine model:4BTA3.9-G11
Number of cylinders:4(PCS)Bore x stroke:102*120mm
Fuel consumption power:210g/kw.hUnit size:2600/1450/1000mm L/W/H
Unit weight:1520kg
Unit model:VGF-DKJY-80
Main power:80KWReserve power:92KW
Current:144ADiesel engine model:6BT5.9-G1
Number of cylinders:6(PCS)Bore x stroke:102*120mm
Fuel consumption power:221g/kw.hUnit size:2900/1650/1200mm L/W/H
Unit weight:1950kg
Unit model:VGF-DKJY-100
Main power:106KWReserve power:116KW
Current:190ADiesel engine model:6BTA5.9-G2
Number of cylinders:6(PCS)Bore x stroke:102*120mm
Fuel consumption power:212g/kw.hUnit size:2900/1650/1200mm L/W/H
Unit weight:2150kg
Unit model:VGF-DKJY-120
Main power:140KWReserve power:155KW
Current:252ADiesel engine model:6BTAA5.9-G2
Number of cylinders:6(PCS)Bore x stroke:102*120mm
Fuel consumption power:215g/kw.hUnit size:2900/1650/1200mm L/W/H
Unit weight:2190kg
Unit model:VGF-DKJY-150
Main power:163KWReserve power:180KW
Current:293ADiesel engine model:6CTA8.3-G1
Number of cylinders:6(PCS)Bore x stroke:114*135mm
Fuel consumption power:212g/kw.hUnit size:3250/1750/1250mm L/W/H
Unit weight:2620kg
Unit model:VGF-DKJY-180
Main power:180KWReserve power:203KW
Current:324ADiesel engine model:6CTAA8.3-G2
Number of cylinders:6(PCS)Bore x stroke:114*135mm
Fuel consumption power:209g/kw.hUnit size:3500/1850/1300mm L/W/H
Unit weight:2980kg
Unit model:VGF-DKJY-200
Main power:220KWReserve power:242KW
Current:396ADiesel engine model:6LTAA8.9-G2
Number of cylinders:6(PCS)Bore x stroke:114*135mm
Fuel consumption power:199g/kw.hUnit size:3500/1850/1300mm L/W/H
Unit weight:3070kg
Unit model:VGF-DKJY-280
Main power:280KWReserve power:308KW
Current:504ADiesel engine model:QSM11-G2
Number of cylinders:6(PCS)Bore x stroke:125*147mm
Fuel consumption power:193g/kw.hUnit size:3900/1850/1300mm L/W/H
Unit weight:3980kg
Unit model:VGF-DKJY-300
Main power:340KWReserve power:380KW
Current:612ADiesel engine model:6ZTAA13-G3
Number of cylinders:6(PCS)Bore x stroke:130*163mm
Fuel consumption power:197g/kw.hUnit size:3900/1850/1300mm L/W/H
Unit weight:4050kg
Unit model:VGF-DKJY-350
Main power:390KWReserve power:415KW
Current:702ADiesel engine model:6ZTAA13-G2
Number of cylinders:6(PCS)Bore x stroke:130*163mm
Fuel consumption power:197g/kw.hUnit size:4100/2100/1450mm L/W/H
Unit weight:4680kg
Unit model:VGF-DKJY-400
Main power:400KWReserve power:415KW
Current:720ADiesel engine model:6ZTAA13-G4
Number of cylinders:6(PCS)Bore x stroke:130*163mm
Fuel consumption power:197g/kw.hUnit size:4200/2200/1550mm L/W/H
Unit weight:4980kg
Unit model:VGF-CKJY-450
Main power:450KWReserve power:470KW
Current:810ADiesel engine model:QSZ13-G3
Number of cylinders:6(PCS)Bore x stroke:136*163mm
Fuel consumption power:193g/kw.hUnit size:4700/2300/1700mm L/W/H
Unit weight:5700kg
